Compact LPF Optical Component: Suitable for Portable Optical Devices
  • Compact LPF Optical Component: Suitable for Portable Optical Devices
  • Compact LPF Optical Component: Suitable for Portable Optical Devices

Compact LPF Optical Component: Suitable for Portable Optical Devices

Place of Origin Shanghai
Brand Name Honghui Guanglian
Certification ISO9001:2015/ISO14001:2015/ ISO45001:2018/ISO27001:2013
Document LPF.pdf
Product Details
Operating Wavelength λo (nm):
1060~1340
Passband Wavelength Range (nm):
1250~1340
Reflection Wavelength Range(nm):
1060~1220
Maximum Insertion Loss Over Pass-band(dB):
<0.2
Ripple In Pass-band(dB):
<0.15
Polarization Dependent Loss(dB):
<0.1
Reflection Isolation(dB):
>13
Passband Lsolation(dB):
>25
Reflection Of Backside AR Coating(%):
<0.25% Over Passband Width
Thermal Wavelength Drift(pm/℃):
<1.0
Polarization Mode Dispersion Within Passband(ps):
≤0.10
Angle Of Incidence(AOI):
1.8°
Scratch/Dig(um):
40/20
Dimension(Length*width*Thickness)(mm):
(1.4±0.1)*(1.4±0.1)*(1.0±0.1)
Operation Temperature:
-40~+85℃
Storage Temperature:
-40~+85℃
Highlight:

compact dwdm filter

,

compact 100ghz filter

Payment & Shipping Terms
Minimum Order Quantity
10
Price
Negotiation
Packaging Details
Specified Plastic Box
Delivery Time
14 work days
Payment Terms
T/T
Supply Ability
10K
Product Description

Product Description

LPF (Long-Pass Filter) is a critical high-performance optical component designed to transmit long-wavelength light while effectively blocking shorter wavelengths, enabling precise light signal separation in various optical systems. Engineered with advanced thin-film coating technology and high-purity optical substrates (such as fused silica or optical glass), this LPF ensures sharp cut-off edges, minimizing wavelength overlap between transmitted and blocked light.

With excellent optical performance, the filter offers high transmittance (>90%) for target long wavelengths and deep blocking (>OD4) for unwanted short wavelengths, significantly improving signal-to-noise ratio in optical detection. Its robust construction features scratch-resistant and moisture-proof coatings, ensuring stable operation across a wide temperature range (-20°C to 70°C) and harsh environmental conditions. Whether integrated into imaging systems, spectrometers, or optical communication devices, LPF provides reliable light filtering solutions, supporting accurate data acquisition and high-performance operation in scientific research, industrial production, and medical diagnostics.


Key Features

Precise Wavelength Selection: Sharp cut-off wavelength (customizable from 350nm to 2500nm) for accurate separation of long/short wavelengths.

High Optical Efficiency: High transmittance for target wavelengths and deep blocking of stray short wavelengths, reducing signal interference.

Durable Construction: Scratch-resistant, moisture-proof coatings and high-purity substrates ensure long-term reliability and stability.

Broad Compatibility: Suitable for integration with spectrometers, cameras, sensors, and other optical devices across multiple industries.

Wide Operating Range: Performs stably in extreme temperatures and humid environments, adapting to laboratory and field applications.

Customizable Options: Tailorable cut-off wavelength, size, and mounting design to match specific system requirements.



Applications

Biomedical Imaging: Used in fluorescence microscopy, flow cytometers, and medical diagnostic devices to filter unwanted short-wavelength background light.

Industrial Inspection: Applied in machine vision systems for semiconductor, display panel, and food packaging inspection to enhance image clarity.

Spectroscopy Analysis: Integrated into UV-Vis-NIR spectrometers for chemical analysis, environmental monitoring, and material composition testing.

Optical Communication: Utilized in fiber optic systems to block short-wavelength noise and ensure stable long-wavelength signal transmission.

Astronomical Observation: Employed in small telescopes and astronomical imaging equipment to filter atmospheric short-wavelength interference.

Portable Sensing Devices: Compatible with handheld optical sensors for on-site testing (e.g., water quality analysis, food safety detection).
