Bare Fiber Pigtail
| Place of Origin | Shanghai |
| Brand Name | Honghui Guangllian |
| Certification | ISO9001:2015/ISO14001:2015/ ISO45001:2018/ISO27001:2013 |
| Model Number | 1.8/1.0mm Pigtail |
| Document | Circle Bare Fiber Pigtail2.xls |
Product Details
Central Wavelength:
1260~1670nm,980&1550nm,900~1100nm, 800~1000nm,1310&1550nm
Insertion Loss:
＜0.03dB
Return Loss:
≥65dB
Reflection@operating Bandwidth:
R＜0.1%@operating Wavelength
Fiber Account:
Single Fiber, Dual Fibers, Dual Holes, Four Fibers, Multiple Fibers
Working Temperature:
-20~75°C
Storage Temperature:
-40~85℃
Fiber Length:
0.8~4.0m
Pigtail Tips O.D.:
Dia 0.7,1.0, 1.8mm Or Specified
Pigtail Tips Length:
2.0~8.0mm
Wedge:
4±0.5°,6±0.5°,8±0.5°,10±0.5°
Polishing Direction:
90±5°,0±5°
Fiber Type:
SM/MM/PM/High Power/Specified
Package Type:
Spcified Package
Highlight:
1.8mm fiber pigtail
,1000nm fiber pigtail
,1.8mm fiber optic pigtail
Payment & Shipping Terms
Minimum Order Quantity
100
Price
Negotiation
Packaging Details
Individual Package
Delivery Time
7 work days
Payment Terms
T/T
Supply Ability
100K
Product Description
Bare Fiber Pigtail
Technical Specifications
| Central Wavelength | 1260~1670nm, 980&1550nm, 900~1100nm, 800~1000nm, 1310&1550nm |
| Insertion Loss | <0.03dB |
| Return Loss | ≥65dB |
| Reflection@operating Bandwidth | R<0.1%@operating wavelength |
| Fiber Account | Single Fiber, Dual Fibers, Dual holes, Four Fibers, Multiple Fibers |
| Working Temperature | -20~75°C |
| Storage Temperature | -40~85℃ |
| Fiber Length | 0.8~4.0m |
| Pigtail Tips O.D. | Dia 0.7, 1.0, 1.8mm or Specified |
| Pigtail Tips Length | 2.0~8.0mm |
| Wedge | 4±0.5°, 6±0.5°, 8±0.5°, 10±0.5° |
| Polishing Direction | 90±5°, 0±5° |
| Fiber Type | SM/MM/PM/High Power/Specified |
| Package Type | Specified Package |
Product Description
Bare Fiber Pigtail AR (Φ1.8/1.0mm Pigtail)
Key Features
- Low insertion loss
- Smooth end face
- Miniature crack
- Firm coating film
- Handle Power up to 20W
Applications
DWDM/CWDM/FWDM Component
Isolator/Circulator Component
Polarization Component
